Master
Bond UV15-7HP is a low viscosity, easy to apply, one-part, UV curable
adhesive system.
Optimal adhesion is achieved in bond line thicknesses of 0.001-0.003
inch, and it can cure rapidly with a minimum intensity of 20-40
milliwatts/cm2 using a
UV
light source emitting at a wavelength of 320-365 nm. The material can
also be cured in sections up to 0.125 inch thick under appropriate
conditions,
making it suitable for bonding, sealing, coating, and encapsulation.
UV15-7HP
has a strong performance profile, featuring a tensile strength of
6,000-7,000 psi and a tensile modulus of 250,000-300,000 psi at room
temperature.
This
toughened system resists thermal cycling and offers significant
elongation of 5-10%. It is an electrically insulative material with a
volume resistivity greater
than
1014 ohm-cm. Optically clear with a refractive index of 1.54
at 589 nm, it is not oxygen inhibited and contains no solvents or
diluents.
UV15-7HP
bonds well to a wide variety of substrates including glass, ceramics,
metals and many plastics, such as polycarbonates, acrylics and polyester
films.
This
system is serviceable in a wide range of temperatures from -80°F to
300°F. It is available in various packaging options: 10cc and 30cc
syringes, ½ pints, pints, quarts, gallons, and 5-gallon containers.
|
